Revit family studio
Revit families that carry their own data sheet.
We build fully parametric Revit families for building-product manufacturers and design teams. Each one ships with checked IFC, COBie, classification and carbon data, and a 3D viewer you can put on your own product pages.
- Revit releases
- 2023 – 2027
- openBIM
- IFC 4.3 · COBie 2.4
- File size target
- Under 1 MB
- Web embed
- One line of HTML
Live family. Change any parameter. The geometry, formulas, warnings and data come from the same rules we put in the .rfa.
Five sample families · demo manufacturer data
Authored to
- ISO 19650
- IFC 4.3 · ISO 16739-1:2024
- COBie 2.4
- Uniclass 2015
- MasterFormat · UniFormat
- ISO 7817-1 LOIN
- ETIM
- EN 15804+A2
- GS1 GTIN
Why it matters
Specifiers pick the product whose data they can use.
Architects drop content that bloats their models or leaves schedules blank. Manufacturers whose families arrive complete get placed in the model, and stay there through tender.
-
22%
of manufacturers offer BIM objects for all of their products. 73% offer them for at least some.
NBS Digital Construction Report, 2025 -
88%
of specifiers say an Environmental Product Declaration matters when they choose a product.
NBS survey of 591 professionals, 2023 -
74%
of architects leave a manufacturer’s site if they can’t find what they need in a few clicks. 61% of them go to a competitor.
AIA survey of 150 architects, 2018
What ships
Every family arrives as a full transmittal.
One source of truth produces the Revit file, the IFC object, the web model and the data sheet, so they never disagree.
| No. | Deliverable | Format | Used for |
|---|---|---|---|
| KF-01 | Revit family, authored in the oldest release you support and upgraded to each newer one | .rfa | Design and documentation |
| KF-02 | Type catalog for large product ranges | .txt | Loading only the types a project needs |
| KF-03 | Shared parameter file with fixed GUIDs | .txt | Schedules and tags that work in every project |
| KF-04 | IFC 4.3 object with mapped property sets | .ifc | openBIM tools and IFC e-submissions |
| KF-05 | Web model with metadata in glTF extras, plus AR file | .glb · .usdz | Your website viewer and AR |
| KF-06 | Product data sheet: COBie, classification, carbon | .xlsx · .json | Specifiers, FM teams and BIM platforms |
| KF-07 | QA report: checks passed, file size, warnings, test-project views | Your sign-off | |
| KF-08 | Embed snippet and analytics dashboard | HTML | Product pages and sales tools |
Services
From one family to a full product range.
-
For building-product manufacturers
Manufacturer content programmes
Turn a catalogue into a specifiable Revit library: type catalogs for large ranges, platform-ready packages and a viewer for every product page.
-
For architects and engineers
Custom families for design teams
Office-standard and project-specific families built to your template, shared parameters and BIM execution plan.
-
For BIM managers
Library audit and rebuild
We test existing content against our standard, strip imported CAD, fix broken formulas and map everything to shared parameters.
-
For manufacturers and owners
Data enrichment
COBie, IFC property sets, EPD carbon values, ETIM classes and GS1 identifiers added to families you already have.
-
For marketing and sales teams
Web viewer and configurator
The family’s own parameters, live in a 3D viewer on your website, with gated downloads and analytics.
-
For every client
Version care
A yearly upgrade to each new Revit release, change logs, and republishing to every platform you list on.
Data standard
Eight groups of data, mapped once, exported everywhere.
Each value is traced to a document you supplied and stored as a shared parameter, so it fills Revit schedules, IFC property sets, COBie sheets and the web viewer from the same place.
| Group | Example parameters | Standard |
|---|---|---|
| Identity | Manufacturer, Model, GTIN, URL, Type Mark, Cost | Pset_ManufacturerTypeInformation · GS1 |
| Geometry | Width, Height, clearances, mounting height, connectors | Revit templates · ISO 7817-1 |
| Classification | Uniclass Pr and Ss, MasterFormat, UniFormat, Assembly Code | Uniclass 2015 · CSI |
| openBIM | IfcExportAs, PredefinedType, Pset_*Common | IFC 4.3 · bSDD |
| Operations | Warranty, expected life, replacement cost | COBie 2.4 |
| Performance | Fire rating, Rw, U-value, lumens, flow rates, loads | EN · ASTM · IES |
| Sustainability | GWP A1–A3, EPD number, recycled content, end of life | EN 15804+A2 · ISO 14025 |
| Passport | GS1 Digital Link, certifications, accessibility | EU CPR 2024/3110 |
Web viewer
Put the family on your product page.
Visitors turn the model, switch types and read the data without a plugin or an Autodesk account. Your team sees which products and sizes they look at.
Process
Ten working days for a typical ten-family range.
- Day 1–2
Intake
Send datasheets, CAD or STEP files, price lists and EPDs. We return a data map for sign-off.
- Day 2–3
Schema mapping
Each value is assigned a shared parameter, IFC property, COBie field and classification code.
- Day 3–7
Parametric modelling
Reference planes, constraints, formulas and nested parts, with coarse, medium and fine detail.
- Day 7–8
Automated QA
Scripted checks on naming, parameters, file size and IFC mapping, then a test in a live project.
- Day 8–9
Versions and exports
Upgraded to each Revit release you support, plus IFC, GLB, USDZ and the data sheet.
- Day 10
Publish
Viewer live on your site, packages on BIM platforms, analytics switched on.
Pricing
Fixed prices per family. Hosting by the month.
Family production
-
Standard
USD 400 per family, from
Furniture, fittings and fixtures with a fixed set of types.
- Up to 25 types and 20 user parameters
- Medium detail (about LOD 300), three detail levels
- Full data package: identity, classification, IFC, COBie
- QA report and one revision round
-
Configurable
USD 1,000 per family, from
Products with formulas, nested parts and large type catalogs.
- Type catalogs up to 2,000 types
- Formulas, constraints and nested shared families
- Rules sheet shared with the web configurator
- EPD carbon values and Revit 2023–2027 files
-
Engineered
USD 2,500 per family, from
Multi-configuration products with MEP connectors.
- Connectors with flow, pressure or electrical data
- Photometric files and clearance zones
- LOD 350–400 detail where fabrication needs it
- Connector and calculation test report
Viewer hosting
-
Showcase
USD 250 per month
A data-rich 3D view on every product page.
- Up to 25 products
- Type switching, dimensions and data panel
- Open RFA and IFC downloads, no login
- 20,000 views a month
-
Specify
USD 490 per month
For teams that want leads and usage data.
- Up to 150 products, live configurator
- Configured families emailed as RFA after a short form
- Analytics on views, configurations and downloads
- AR on iOS and Android, your branding
-
Enterprise
USD 10,000 per year, from
For large catalogues and distributor networks.
- Unlimited products and views
- SSO, API and webhooks into your CRM
- Product passport pages on GS1 Digital Link
- Named support and uptime commitment
Every programme starts with a paid data audit of one product line (USD 2,500–4,000), credited against the build. Content care, which covers each new Revit release, classification updates and new SKUs, is 15–20% of build value a year. Prices in US dollars, before tax.
